Replace Upper Control Arms On A8 D3

12/16/2017 – Due to the tires worn out on both inner/outer – I decided to check the Control Arms since they’re both Karlyn. Anyhow, it turned out still GOOD. It must be the alignment. I bought the CA from FCPEuro just in case they failed, returned it with full refund without any problem – just the cost of UPS to ship back was outragous… Great company.

Tires worn out inner/outer due to alignment

2017-02-27 Right – Upper – Front Karlyn failed after 9 months.

2015-05-30

In attempt to eliminate the suspension noise from backing out of the drive way on the cold days, I bought some upper control arms and stabilizer brackets and replace them. This is how I replaced mine. I’m sure there are many ways to do it. The procedure is very straight forward, except for the bolt that got stuck until we lower the shock assembly down to clear it. All bolts and nuts use 16mm size wrenches. It’s also more convenient if we remove the whole strut assembly to replace both upper control arms.

A8 D3 Upper Control Arms New and Old     A8 D3 Loosen Shock Assembly Bolts

A8 D3 loosen bolt height     A8 D3 Stabilizer Bracket orientation

Driver Side

Passenger Side

All components were bought from FCPEuro.



6 Replies to “Replace Upper Control Arms On A8 D3”

  1. Thanks for the link. I find your site very informative. Also is an alignment required after you did the upper control rods and stabilizer bracket? Thanks

      1. Can I ask you what brand you got? I am torn between the price and knowing the quality of the other brands.
